Features
- The pump casing is made of macromolecule plastic, and the motor casing is made of stainless steel, more beautiful and more banausic.
- This pump can be used for transferring seawater, liquid medicine beverage milk and those corrosive liquid whose physical characteristic is similar as water.
- Cylinder water-cooled design ensures such features as the possibility of ground use of the submersible pump.
- Preventing being overheated after motor's long time operation, long use time and easy maintenance.
- It is also equipped with 1-phase capacitance operation asynchronism motor, the protector in which can automatically cut on the power when it overheated or over currented, thus guarantee the security and reliability of pump's operation even in the atrocious environment.
- Remark: VQPR-VH 370M is low level residue drainage pump. Maximum emptying level 2mm from the bottom
Applications
- VQPR-VH are suitable for use in applications such as draining small flooded areas (rooms, cellars, garages) in the event of an emergency, for the disposal of waste water in the home (from dishwashers, washing machines) and for emptying drainage traps.
- Also it is perfect for water tank, hot tub, rain barrel, swimming pool, garden ponds, etc.
Working Condition
- Max Immersion Depth: 5m
- Max Liquid Temp.: +40。C
- Liquid PH Scope: 6.5-8.5
- Max Diameter of Solid: 0.2mm.
Product Specifications
| Model | Power kw |
Outlet mm |
Voltage V/Hz |
Max Flow l/min |
Max Head m |
G.W. kg |
Dimensions cm |
| VQPR-VH-100M | 0.10 | 25 | 220/50 | 70 | 6 | 3,3 | 18×16.5×30 |
| VQPR-VH-370M | 0.37 | 32 | 220/50 | 130 | 7 | 5.3 | 20x19x31 |
Download detailed product information here.
- Download catalog. Click here
- Download user manual. Click here
